EXFO PXM-LXM-SM1
MPO Singlemode Tier-1 certification kit
Rent or Lease
EXFO - PXM-LXM-SM1
Tier-1 MPO-12 fiber certification power meter and light source kit with fastest loss and length measurement based on certification standards for singlemode fibers.
PXM-LXM-SM1 Product Highlights
• Leading FasTesT™ performance: test MPO-12 cables at 2 wavelengths in just 1 second
• Dual wavelength on light source
• Insertion loss measurement
• Polarity type validation
• Up to 25 km in length measurement
• In-line visual fault locator (VFL) for fiber tracing on LXM
• Comprehensive results combined on one page
• PXM with contactless connector
• 4-inch color touchscreen
• Native MPO-12 connector on devices
EXFO & TRS-RenTelco
TRS-RenTelco is a proud partner of EXFO and offers a wide range of rental, purchase and leasing solutions designed specifically to meet the evolving needs of the electronic testing industry. Our close relationship with EXFO allows us to ensure we have the right Optical Test solution for your job.
Renting Optical Test
With TRS-RenTelco, renting Optical Test equipment has never been easier. Enjoy same-day shipping, lease, and finance options on our inventory of over 5000 electronic testing equipment rentals. As one of North America’s largest test equipment rental providers, it is our mission to support the endeavors of our clients no matter how big or small with reliable expertise, excellent customer service, accuracy, and speed.
Links to Additional Information
EXFO Products from TRS-RenTelco
- Configurations
- Resources
- FAQsAI
--, GP-10-061, LXM-SM1, MPO-SM-TJ-kit1, PXM
See Configuration Details
-
GP-10-061
Medium soft carrying case
-
LXM-SM1
Singlemode Multi-fiber Light source 1310/1550nm
-
MPO-SM-TJ-kit1
Singlemode MPO-12 Test Jumper kit
-
PXM
Multi-fiber power meter
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
SOFT CASE
Qty: 1 -
WALL-MOUNT AC/DC POWER SUPPLY 20W.
Qty: 2 -
Type A MPO12 FEMALE/FEMALE APC 3M/12S.
Qty: 2 -
Type A MPO12 MALE/FEMALE APC 3M/12S
Qty: 1 -
Type A MPO12 MALE/MALE APC 0.5M/12S.
Qty: 1 -
SW-Software and Manuals
Qty: 1 -
Adapter MTP (APC)
Qty: 3 -
USB C to USB C cable
Qty: 2
*This item has already been added to your cart. Check your cart for quantity and availability.
EXFP PXM LXM Datasheet v7
Content is AI-generated. Verify critical details with manufacturer-provided resources.
What is the fastest test time achievable with the EXFO PXM/LXM SM1?
The PXM/LXM SM1 features EXFO's FasTesT technology, which can test duplex and multi-fiber cables at 2 wavelengths in just 1 second, the fastest test time in the industry. This rapid testing capability automatically provides loss per channel at the 2 selected wavelengths, along with length and polarity type of the link under test when continuity is detected, significantly improving efficiency in large-scale fiber deployment projects.
How many fibers can the PXM/LXM SM1 test simultaneously?
The PXM/LXM SM1 supports native duplex and 8/12 fiber-based testing directly. It can also test 16 and 24 fiber-based configurations in 1 second using loopback or dual test set methods. This versatile testing capability addresses the needs of base 8, 12, 16, and 24 fiber applications commonly used in AI supercomputer clusters, hyperscaler data centers, and enterprise networks.
What certification standards are built into the EXFO PXM/LXM SM1?
The PXM/LXM SM1 includes onboard certification standards covering both network and cabling standards. Network standards include 40GBASE-SR4, 100G-PSM4 2.0, 100GBASE-SR2/SR4, 200GBASE-SR2/DR4, 400GBASE-DR4/SR4.2/SR8, 128GFC-PSM4/SW4, and 256GFC-SW4. Cabling standards include ISO/IEC 14763-3:2014, TIA-568.3-D (inside and outside plant), and EN50173:2011, with a dynamic loss calculator for flexible testing.
What is the Click-Out adapter system on the PXM/LXM SM1?
The PXM/LXM SM1 features a unique Click-Out adapter system that provides unmatched versatility for testing various connector types. The system is compatible with duplex MDC, SN, and LC connectors, as well as MPO and SYSTIMAX MTP connectors. The Pro version includes both native MPO-12 fixed ports and Click-Out adapter ports for duplex testing, allowing technicians to handle diverse fiber installations with a single test set.
Does the PXM/LXM SM1 include visual fault location capabilities?
Yes, the LXM light source includes an in-line visual fault locator (VFL) on the same port as the MPO source itself. This convenient integration allows technicians to trace a fiber right to the other end of the link, helping the remote technician easily find the MPO port for connection. The VFL also makes it easy to locate macrobends or breaks in the fiber during troubleshooting.
What polarity types can the PXM/LXM SM1 validate?
The PXM/LXM SM1 provides comprehensive polarity validation for both duplex and multi-fiber cables. For multi-fiber connections, it identifies polarity types A, B, C, or U with graphical representation. For duplex fibers, it validates polarity types A-A and A-B. The system provides pass/fail status comparing actual polarity type versus expected polarity type, helping ensure proper cable deployment.
What length measurement capabilities does the EXFO PXM/LXM SM1 offer?
The PXM/LXM SM1 can measure fiber length up to 25 km, providing accurate distance measurements for each fiber in the cable. Length measurements are displayed alongside insertion loss and polarity information on the comprehensive results screen, giving technicians full visibility into the physical characteristics of the link under test for both documentation and troubleshooting purposes.
What warranty coverage does the EXFO PXM/LXM SM1 include?
The PXM/LXM SM1 comes with a 3-year warranty and calibration interval, providing extended peace of mind for repairs and calibration services. This extended warranty coverage reflects EXFO's confidence in the reliability and accuracy of the unit, reducing overall cost of ownership and ensuring consistent performance throughout the warranty period.
