Megger S1-552/2

5 kV Insulation Tester

The Megger S1-552/2 resistance tester is designed for the testing and maintenance of high voltage equipment. The S1-552/2 CAT IV 600 V safety rating makes it safe for use in the widest range of applications. The instruments drive 5 mA of short circuit current allows for faster charging and testing of large capacitive and inductive loads.

The measurement range of the Megger S1-552/2 has been expanded to 15 T Ohms. The lapsed time is displayed constantly, removing the need for separate timers. The S1-552/2 features include up to three timed measurement positions, which simplifies DAR testing.

The large backlit LCD on the Megger S1-552/2 makes for easy visibility in both bright sunlight and poorly lit environments. Information displayed on the S1-552/2 includes resistance, voltage, leakage current, capacitance, battery status and time constant.

Megger S1-552/2- Features and Specifications:

  • Electrical safety - CAT IV 600 V
  • The equipment can run on mains or can be powered by batteries
  • Easily readable backlit display - Digital or Analog
  • Variable test voltage from 50 to 5000 V
  • Automatic IR (insulation resistance), PI (polarization index), DAR (dielectric absorption ratio), SV (step voltage) and DD (dielectric discharge) testing
  • Insulation range measurement - 15 TO (5 kV model) and 35 TO (10 kV model)
  • Fast charging with 5mA output current
  • Ease of download - RS232 and USB (result download to Megger Download Manager)
  • Error free record keeping with on board memory/result storage

The Megger S1-552/2 is available for lease or purchase from TRS-RenTelco with 24/7 customer support.

The latest test equipment - We understand your interests in having the latest and the best in test equipment and are one of the first to buy newly introduced equipment from top T&M manufacturers. If you need a new equipment model, we probably have

Read More
  • Configurations
  • Resources
Base Model
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
  • Cord Power

    Qty: 1
  • Cable DB 9(f) - DB 9(f)

    Qty: 1
  • Cable USB-A - USB-B

    Qty: 1
  • Pouch Lid Mounted

    Qty: 1
  • USB Drive with Software and Manuals

    Qty: 1
  • Software Download Manager

    Qty: 1
  • LEAD SET with 3KV INSULATED CLIPS, 3meter

    Qty: 1
  • LEAD SET with 3KV INSULATED CLIPS, 3meter

    Qty: 1
  • LEAD SET with 3KV INSULATED CLIPS, 3meter

    Qty: 1
