Tektronix TPR4000
A low noise, offset.ripple on DC rails from –60 to +60 VDC.
Use the Tektronix TPR4000 power rail probe to efficiently probe digital power management, memory and Ethernet connectivity, noise sources on high-frequency power rails, and chipsets for power rail voltage supply and control. The TPR4000 offers the lowest noise and high bandwidth required to measure AC ripple between 200 uVp-p and 800 mVp-p at up to 4GHz.
This power rail probe's higher input impedance minimizes the oscilloscope loading effect on DC rails to make the needed measurements.
Tektronix TPR4000 Features and Specifications:
- Bandwidth: 4GHz
- Offset voltage range: 60V
- Dynamic range: 1V
- Input resistance: 50 k ohmes DC 50 ohmes AC
- Attenuation: 1.25x
- DC coupling mode: DC 4GHz
- DC reject mode: 10kHz to 4GHz
- Dynamic range: up to 60V DC, 1V p-p AC
- DC linearity: <0.1 percent
- DC offset drift: 100 uV
- Step response long-term aberrations: 1 percent
- Input impedance: 50 k ohmes DC to 10kHz, 50 ohmes AC > 100kHz
- Compatible with the 6 series MSO, 5 series MSO, DPO7000, and other oscilloscopes
The Tektronix TPR4000 Active Power Rail Probe is available for rent or lease at TRS-RenTelco with 24/7 support. To learn more about our calibrated test equipment, call us at 800.874.7123.
- Configurations
- Resources
Base Model
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Marker Kit
Qty: 1 -
Adapter MMCX 0.100 Center 0.025 Square Pin
Qty: 1 -
Pin Kit DUT Interface
Qty: 1 -
Support Align Probe with Living Hinge
Qty: 1 -
Carrycase Hard
Qty: 1 -
Cable Assembly RF 50 Ohm SMA(m) - MMCX
Qty: 1 -
Cable Assembly RF 50 Ohm SMA(m) - SMA(m)
Qty: 1 -
Cable Assembly RF MMCX(f) - U.FL(m) 50 Ohm Micro Coax
Qty: 1 -
Lead Y MMCX(f) - 0.8 mm Sockets
Qty: 1 -
Installation Tool for 0.062 Square Pins Over SMT
Qty: 1 -
Wirecard
Qty: 1
