Rohde & Schwarz ZNBT26
12 -port, 100 KHz to 26.5 GHz Network Analyzer
Rent or Lease
Rohde & Schwarz - ZNBT26
The R&S®ZNBT is a multiport vector network analyzer offering up to 24 fully integrated test ports. The instrument can simultaneously test multiple DUTs or measure one DUT with up to 24 ports. The fully integrated test ports make the R&S®ZNBT a true multiport vector network analyzer, which includes a wide dynamic range, high output power levels and fast measurements. Frequency ranges up to 40 GHz are avalailable.
ZNBT26 Product Highlights
• Frequency range: 9 kHz to 8.5 GHz or 100 kHz to 20/26.5/40 GHz
• Up to 24 ports with fully phase coherent receivers
• Dynamic range of up to 140 dB
• Short sweep times of 1.7 ms (R&S®ZNBT8) and 2.7 ms (other models)
