Rohde & Schwarz HE300
Active directional antenna
The Rohde & Schwarz HE300 is an active directional antenna. It can be used to locate transmitters and interference sources, if combined with portable receivers such as the Rohde & Schwarz PR100. The HE300 comes with 3 exchangeable sub-range antenna modules, which cover a frequency range of 20 MHz to 7.5 GHz, with an additional module HE300HF to handle frequencies from 9 kHz to 20 MHz.
When the HE300 is operating under the Active Mode, a built-in, low-noise wideband amplifier can be activated to enhance system sensitivity and the same can be bypassed in Passive Mode. The Rohde & Schwarz HE300 is both compact and lightweight, which makes it well-suited for easy handling and operation in field conditions, and has an N type male connector.
Rohde & Schwarz HE300 Usage: handheld or mounted on tripod
Some of the key features of the Rohde & Schwarz HE300 include:
- Horizontal and vertical polarization
- Unambiguous direction finding
- Direction finding by orienting antenna towards maximum signal strength
- %22Passive%22 and %22Active%22 mode create wide dynamic range
- 3 exchangeable antenna modules
Get the Rohde & Schwarz HE300 active directional antenna for rent or for purchase from TRS-RenTelco with 24/7 customer support. Upon purchase of this equipment, we also offer a 12 months part and labor warranty. All products come calibrated to stringent standards in our 50 GHz ANSI/NCSL Z540-1 compliant laboratory by an experienced team of metrologists and technicians. Request a quote today.
- Configurations
- Resources
--, HE300HF
See Configuration Details
-
HE300HF
Loop Antenna As HF Option For HE300 9 kHz To 20 MHz (Fitting Into Transport Case Of HE300)
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Battery AA
Qty: 6 -
Battery Holder
Qty: 2 -
Antenna Module 20 MHz - 200 MHz
Qty: 1 -
Antenna Module 200 MHz - 500 MHz
Qty: 1 -
Antenna Module 9 KHz - 20 MHz
Qty: 1 -
Antenna Module 500 MHz - 7500 MHz
Qty: 1 -
Display Unit
Qty: 1 -
Carrycase
Qty: 1 -
USB Drive with Software and Manuals
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
Base Model
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
USB Drive with Software and Manuals
Qty: 1 -
Display Unit
Qty: 1 -
Antenna Module 20 MHz - 200 MHz
Qty: 1 -
Antenna Module 500 MHz - 7500 MHz
Qty: 1 -
Antenna Module 200 MHz - 500 MHz
Qty: 1 -
Battery Holder
Qty: 2 -
Carrycase
Qty: 1 -
Battery AA
Qty: 6
*This item has already been added to your cart. Check your cart for quantity and availability.
Base Model
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
USB Drive with Software and Manuals
Qty: 1 -
Display Unit
Qty: 1 -
Antenna Module 20 MHz - 200 MHz
Qty: 1 -
Antenna Module 500 MHz - 7500 MHz
Qty: 1 -
Antenna Module 200 MHz - 500 MHz
Qty: 1 -
Battery Holder
Qty: 2 -
Carrycase
Qty: 1 -
Battery AA
Qty: 6
*This item has already been added to your cart. Check your cart for quantity and availability.
Rohde & Schwarz HE300 Spec Sheet
