Rohde & Schwarz ESR3
EMI test receiver 9 kHz to 3.6 GHz
The R&S ESR3 is an EMI test receiver with a frequency range of 9 kHz to 3.6 GHz and offers the use of both a signal analyzer and a spectrum analyzer in one device.
Rohde and Schwarz ESR3 - Features and Specifications:
- EMI test receiver and signal/spectrum analyzer combined in a single instrument
- Compliant with CISPR 16-1-1 Ed. 3.1
- Preselection with integrated 20 dB preamplifier
- Resolution bandwidths in line with CISPR and optionally in decade steps from 10 Hz to 1 MHz
(MIL STD-461, DO-160) - Ultrafast time domain scan (option) or conventional stepped frequency scan
- Realtime spectrum analysis with up to 40 MHz span for detailed investigation of disturbances (option)
- Time domain display with high resolution (50 ?s)
- Automatic test routines
- IF analysis (option)
Request a quote to rent or lease the Rohde and Schwarz ESR3 EMI test receiver from TRS-RenTelco.
The latest test equipment - We are constantly investing in new equipment to support emerging technologies that require electronic test and measurement equipment. We are often the first to buy newly introduced products from top T&M manufacturers.
Calibrated equipment - Our experienced team of metrologists and technicians calibrate each product to stringent standards in our 50 GHz ANSI/NCSL Z540-1 compliant laboratory.
- Configurations
- Resources
--, B22, B29, B4, B50, K53
See Configuration Details
-
K53
Time-Domain-Scan, FFT Based Scan For Fast EMI Measurements
-
B4
OCXO, Precision Frequency Reference Aging Per Year: 0.1 Ppm Temp. Drift: 0.1 ppm (5 To 45 °C)
-
B50
Hardware For Time Domain Scan And Real-Time Measurements
-
B29
10Hz Frequency Extension, Incl. Decadical EMI Bandwidths
-
B22
RF Preamplifier 20 dB, 9 kHz to 7 GHz
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Cord Power
Qty: 1 -
Cable DX Adapter
Qty: 1 -
USB Drive Product Documentation
Qty: 1
