Keysight Technologies RP7963A
Regenerative Power System, 950V, +/-20A, 10kW, 400/480 VAC
Achieve sourcing and electrical loading up to 20kW with the Keysight (formerly Agilent) RP7963A regenerative power source.
The Keysight RP7963A is a single output, bi-directional, regenerative DC power supply that offers excellent safety features to protect both your team and your device under test. It also features a compact 3U-high package to save floor space and reduce integration time.
With fast output speeds and sub-millisecond command processing times, the RP7963A power supply seamlessly meets all your test system and HEV/EV requirements while also being cost-effective.
Keysight RP7963A Features and Specifications:
- DC ratings:
- Voltage source: 0V to 950V
- Current source and sink: 0A to plus/- 20A
- Power: 0kW to plus/- 10kW - Output ripple and noise:
- CV peak-to-peak: 1,000mV
- CV rms: 200mV - Voltage load regulation: 60mV
- Current load regulation: 9mA
- Voltage programming accuracy: 0.03 percent 120mV
- Voltage measurement accuracy: 0.03 percent 160mV
- Current programming and measurement accuracy: 0.1 percent 12mA
- Recovery time: 500 us
- Settling band: 2.375V
The Keysight (formerly Agilent) RP7963A regenerative power system (950V, plus/-20A, 10kW, 400/480 VAC) is available for rent or lease at TRS-RenTelco with 24/7 support. To know more or to get a quote, call us at 800.874.7123.
- Configurations
- Resources
Base Model
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Kit Buss Bar Connection
Qty: 1 -
Cover Kit
Qty: 1 -
RJ45 STRAIGHT CABLE
Qty: 1 -
SW-MANUALS
Qty: 1 -
USB Software I/O Libraries, v18.3.29517
Qty: 1
