Keysight Technologies N9010B-544
44 GHz EXA Signal Analyzer, 2.4 mm (m)
Rent or Lease
Keysight Technologies – N9010B-544
The Keysight Technologies N9010B-544 EXA multi-touch signal analyzer helps you achieve maximum value in signal analysis up to millimeter-wave frequencies. Achieve tighter design margins or shorter test times with the Keysight Technologies N9010B-544.
Meet various test requirements with general-purpose measurement applications of the Keysight Technologies N9010B-544 EXA signal analyzer that enable the right balance between performance and price. The Keysight Technologies N9010B-544 is built to handle current and upcoming test needs as it is easily upgradeable on demand.
N9010B-544 Product Highlights
- Frequency Range - 10 Hz to 44 GHz
- Save test time in spurious response measurements with fast sweep capability
- Characterize signals close to noise floor with no compromise to sweep speed
- Achieve cost-effective analysis for millimeter-wave measurements
- Measure the smallest signals with best-in-class level accuracy, DANL & TOI
- The list-sweep mode feature helps perform power measurements quickly at discrete frequency points
- The 89600 VSA software supports more than 75 signal standards and modulation types
- Easily upgrade to new applications and technologies using downloadable X-Series applications
Keysight & TRS-RenTelco
TRS-RenTelco is a proud partner of Keysight Technologies and offers a wide range of rental, purchase and leasing solutions designed specifically to meet the evolving needs of the electronic testing industry. Our close relationship with Keysight Technologies allows us to ensure we have the right Spectrum Analyzer solution for your job.
Renting a Spectrum Analyzer
With TRS-RenTelco renting a Spectrum Analyzer equipment has never been easier. Enjoy same-day shipping, lease, and finance options on our inventory of over 4,400 electronic testing equipment rentals. As one of North America’s largest test equipment rental providers, it is our mission to support the endeavors of our clients no matter how big or small with reliable expertise, excellent customer service, accuracy, and speed.
Additional Information
Manufacturer Home Page | Keysight Technologies.
- Configurations
- Resources
- FAQsAI
--, 544
See Configuration Details
-
544
Frequency Range, 10 Hz To 44 GHz
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Power cord Right Angle
Qty: 1 -
Cover Front
Qty: 1 -
USB Drive Product Documentation
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
--, 544, EA3, EXM, NF2, P44
See Configuration Details
-
544
Frequency Range, 10 Hz To 44 GHz
-
EA3
Electronic Attenuator, 3.6GHz
-
EXM
External Mixing
-
NF2
Noise Floor Extension, Instrument Alignment
-
P44
Preamplifier, 100 kHz - 44 GHz
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Cord Power
Qty: 1 -
Cover Front
Qty: 1 -
USB Drive Product Documentation
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
--, 544, PFR
See Configuration Details
-
544
Frequency Range, 10 Hz To 44 GHz
-
PFR
Precision Frequency Reference
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Power cord Right Angle
Qty: 1 -
Cover Front
Qty: 1 -
USB Drive Product Documentation
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
--, 544, B40, EXM, MPB
See Configuration Details
-
544
Frequency Range, 10 Hz To 44 GHz
-
B40
Analysis Bandwidth, 40 MHz
-
EXM
External Mixing
-
MPB
Microwave Preselector Bypass
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Power cord Right Angle
Qty: 1 -
Cover Front
Qty: 1 -
USB Drive Product Documentation
Qty: 1 -
50 ohm SMA Terminator, male
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
--, 544, P44
See Configuration Details
-
544
Frequency Range, 10 Hz To 44 GHz
-
P44
Preamplifier, 100 kHz - 44 GHz
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Power cord Right Angle
Qty: 1 -
Cover Front
Qty: 1 -
USB Drive Product Documentation
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
--, 544, EXM, NF2, P44, PFR
See Configuration Details
-
544
Frequency Range, 10 Hz To 44 GHz
-
EXM
External Mixing
-
NF2
Noise Floor Extension, Instrument Alignment
-
P44
Preamplifier, 100 kHz - 44 GHz
-
PFR
Precision Frequency Reference
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Power cord Right Angle
Qty: 1 -
Cover Front
Qty: 1 -
USB Drive Product Documentation
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
--, 544, NF2, P44, PFR
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
USB Drive Product Documentation
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
--, 544, EA3, P44, PFR
See Configuration Details
-
544
Frequency range, 10 Hz to 44 GHz
-
P44
Preamplifier, 100 kHz - 44 GHz
-
PFR
Precision frequency reference
-
EA3
Electronic attenuator, 3.6GHz
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
USB Drive Product Documentation
Qty: 1 -
Power cord Right Angle
Qty: 1 -
Cover Front
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
--, 544, B40, EXM, MPB, P44
See Configuration Details
-
544
Frequency Range, 10 Hz To 44 GHz
-
B40
Analysis Bandwidth, 40 MHz
-
EXM
External Mixing
-
MPB
Microwave Preselector Bypass
-
P44
Preamplifier, 100 kHz - 44 GHz
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Power cord Right Angle
Qty: 1 -
Cover Front
Qty: 1 -
USB Drive Product Documentation
Qty: 1 -
50 ohm SMA Terminator, male
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
Content is AI-generated. Verify critical details with manufacturer-provided resources.
What frequency range does the Keysight N9010B-544 EXA signal analyzer cover?
The N9010B-544 extends from 10 Hz to 44 GHz with DC coupling. This millimeter-wave configuration does not support AC coupling. The analyzer operates across multiple bands with different LO multiplication factors, with Band 6 covering 34.4 to 44 GHz using an LO multiple of 8.
How does the N9010B-544 DANL compare to the standard N9010B-526?
The N9010B-544 achieves DANL of -135 dBm from 34.4 to 44 GHz without preamplifier. At mid-band frequencies, performance includes -142 dBm at mid-band 6 (42.7 GHz) with preamplifier off and -154 dBm typical with preamplifier on. Lower frequency performance remains similar to the 526 option with -148 dBm from 10 MHz to 2.1 GHz.
What type of RF connector is used on the N9010B-544?
The N9010B-544 uses a 2.4 mm male connector with 50 ohm nominal impedance for the RF input. This is different from the Type-N female connector used on lower frequency options. The 2.4 mm connector is specifically designed for millimeter-wave frequencies up to 50 GHz.
What is the frequency response accuracy of the N9010B-544 at millimeter-wave frequencies?
At 10 dB input attenuation and 20 to 30 degrees C, the N9010B-544 delivers ±2.5 dB frequency response from 26.4 to 34.5 GHz and ±3.2 dB from 34.4 to 44 GHz. With preamplifier enabled, the specifications are ±2.5 dB from 26.4 to 34.5 GHz and ±3.2 dB from 34.4 to 44 GHz.
Does the N9010B-544 support external mixing capabilities?
Yes, the N9010B-544 supports external mixing with Option EXM. The external mixing port uses an SMA female connector with 50 ohm impedance, triplexed for mixer bias, IF input, and LO output. LO output frequency ranges from 3.75 to 14.0 GHz, enabling frequency extension beyond 44 GHz with compatible external mixers.
What preamplifier options are available for the N9010B-544?
The N9010B-544 can be equipped with Option P44 preamplifier covering 100 kHz to 44 GHz. The preamplifier provides +20 dB nominal gain from 100 kHz to 3.6 GHz and +40 dB nominal gain above 7 GHz. Noise figure ranges from 8 to 12 dB proportional to frequency at lower bands and follows DANL + 176.24 dB nominal above 13.6 GHz.
What is the third-order intermodulation performance of the N9010B-544?
The N9010B-544 achieves third-order intermodulation distortion specifications across its full frequency range. From 100 MHz to 3.95 GHz, TOI is +15 dBm (typical +19 dBm). From 26.5 to 44 GHz, typical TOI is +13 dBm nominal. With preamplifier on and two -45 dBm tones at the preamp input, TOI is 0 dBm nominal from 30 MHz to 3.6 GHz.
What analysis bandwidth options work with the N9010B-544?
The N9010B-544 includes standard 25 MHz analysis bandwidth. Optional bandwidths include 40 MHz with Option B40 and up to 160 MHz with Options B85, B1A, or B1X. The 40 MHz option provides 200 MSa/s at the ADC with 12-bit resolution. However, Option MPB (microwave preselector bypass) is not available on the 544 configuration.
