Keysight Technologies N5225B-419
4-port, 10 MHz - 50 GHz PNA Network Analyzer, 2.4 mm (m)
Rent or Lease
Keysight Technologies - N5225B-419
10 MHz to 50 GHz, 2-ports with one source and 4-ports with two sources, source and receiver attenuators, bias-tees, pulse generators and modulators, noise figure, and best RF performance.
N5225B-419 Product Highlights
• Solve your toughest measurement challenges with the highest-performing microwave network analyzer in the industry.
• Measure S-parameters with the smallest uncertainty and highest stability.
• Efficiently characterize active components with applications that simplify setups.
• Accelerate insight into component behavior using a multitouch display and intuitive user interface.
• Meet your budget and measurement requirements by customizing to the right level of performance.
Keysight Technologies & TRS-RenTelco
TRS-RenTelco is a proud partner of Keysight Technologies and offers a wide range of rental, purchase and leasing solutions designed specifically to meet the evolving needs of the electronic testing industry. Our close relationship with Keysight Technologies allows us to ensure we have the right Network/Impedance Analyzers solution for your job.
Renting Network/Impedance Analyzers
With TRS-RenTelco renting Network/Impedance Analyzers equipment has never been easier. Enjoy same-day shipping, lease, and finance options on our inventory of over 5000 electronic testing equipment rentals. As one of North America’s largest test equipment rental providers, it is our mission to support the endeavors of our clients no matter how big or small with reliable expertise, excellent customer service, accuracy, and speed.
