Dranetz HDPQ-XPLORER-A
HDPQ Xplorer
Dranetz - HDPQ-XPLORER-A
The Dranetz HDPQ XPLORER-A is a power quality analyzer from the Dranetz' HDPQ family of high quality testing products. When you order the Dranetz HDPQ, you get the instrument only. The specifications of the HDPQ XPLORER include the following: 50/60HZ, 16/20HZ, AC/DC, 512 samples/cycle, 1MHZ high speed digitized transients, 8 channels (4 differential voltage, 4 current), 10K cycle recording depth, WVGA touch LCD display, Ethernet, Wi-Fi, Bluetooth, battery charger, voltage cable set with pouch, Answer Modules.
HDPQ-XPLORER-A Product Highlights
• High Definition PQ & Energy Monitoring - 1000Vrms, AC/DC, 512 samples/cycle
• High Speed Digitized Transients - 1us, 10 to 2000Vpk
• Eight channels, 4 voltage & 4 current
• AnswerModules - Sag directivity, PF capacitor identification, motor - automatic event categorization
• Advanced PQ - IEC 61000-4-30 Class A & IEEE 1159 compliant
• Harmonics - IEC 61000-4-7, IEEE 519 (2014)
• Transient capabilities - V & I - waveshape triggers, high speed. Well beyond standards requirements
• IEEE 1459 Advanced Power Measurements
• 10,000 cycle pre/post trigger buffer
• EN 50160 Ed 3
Dranetz & TRS-RenTelco
TRS-RenTelco is a proud partner of Dranetz and offers a wide range of rental, purchase and leasing solutions designed specifically to meet the evolving needs of the electronic testing industry. Our close relationship with Dranetz allows us to ensure we have the right Electrical & Industrial Test Equipment solution for your job.
Renting Electrical & Industrial Test Equipment
With TRS-RenTelco, renting Electrical & Industrial Test Equipment equipment has never been easier. Enjoy same-day shipping, lease, and finance options on our inventory of over 5000 electronic testing equipment rentals. As one of North America’s largest test equipment rental providers, it is our mission to support the endeavors of our clients no matter how big or small with reliable expertise, excellent customer service, accuracy, and speed.
Links to Additional Information
Dranetz Products from TRS-RenTelco
Other Electrical & Industrial Test Equipment from TRS-RenTelco
- Configurations
- Resources
--, SCC-HDPQ
See Configuration Details
-
SCC-HDPQ
Soft Carry Case
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Lead Jumper Banana(m) - Banana(m) Shrouded Short
Qty: 4 -
Cable Pouch
Qty: 1 -
Cable Voltage White
Qty: 4 -
USB Drive 4 GB
Qty: 1 -
Cable USB-A - USB-MicroB
Qty: 1 -
Dolphin Clip Black 1000 V 10 A or Higher
Qty: 4 -
Battery Pack Nickel-Metal Hydride (Ni-MH) 9.6 V 22 W
Qty: 1 -
Clip Dolphin White
Qty: 4 -
Marker Wire Voltage Kit
Qty: 1 -
Cable Assembly Black 6 ft
Qty: 4 -
Marker Wire Current Kit
Qty: 1 -
AC Adapter Wall Transformer
Qty: 1 -
Bluetooth Adapter USB
Qty: 1 -
Manual Quick Reference
Qty: 1 -
Carrycase Soft
Qty: 1 -
Stylus
Qty: 1 -
USB Drive Software and Manuals
Qty: 1 -
USB Drive with Software and Manuals
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
--, GOPROHDPQ, SCC-HDPQ
See Configuration Details
-
GOPROHDPQ
GoPRO HDPQ Driver
-
SCC-HDPQ
Soft Carry Case
Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
-
Lead Jumper Banana(m) - Banana(m) Shrouded Short
Qty: 4 -
Cable Pouch
Qty: 1 -
Cable Voltage White
Qty: 4 -
USB Drive 4 GB
Qty: 1 -
Cable USB-A - USB-MicroB
Qty: 1 -
Dolphin Clip Black 1000 V 10 A or Higher
Qty: 4 -
Battery Pack Nickel-Metal Hydride (Ni-MH) 9.6 V 22 W
Qty: 1 -
Clip Dolphin White
Qty: 4 -
Marker Wire Voltage Kit
Qty: 1 -
Cable Assembly Black 6 ft
Qty: 4 -
Marker Wire Current Kit
Qty: 1 -
AC Adapter Wall Transformer
Qty: 1 -
Bluetooth Adapter USB
Qty: 1 -
Manual Quick Reference
Qty: 1 -
Carrycase Soft
Qty: 1 -
Stylus
Qty: 1 -
USB Drive Software and Manuals
Qty: 1 -
USB Drive with Software and Manuals
Qty: 1
*This item has already been added to your cart. Check your cart for quantity and availability.
Dranetz HDPQ-XPLORER-A Spec Sheet
Dranetz HDPQ-XPLORER-A Brochure
Dranetz HDPQ-XPLORER-A Quick Reference Guide
