Doble Engineering M4000

Insulation Analyzer

The M4000 from Doble is the leading instrument for evaluating the condition of high-voltage power apparatus. The instrument evaluates the integrity of high-voltage substation apparatus by measuring the power factor/tangent delta and a number of other values. It also measures capacitance, to evaluate physical changes to the apparatus. With a maximum output of 300 mA at 10 kV, the Doble M4000 offers high charging current, allowing you to run single-phase exciting current tests at higher voltages, increasing the turn-to-turn stress.

The M4000 has the power to test a wide range of apparatus, making it highly versatile. It also uses a patented technique called Line Frequency Modulation, in which measurements are made at a frequency above and below the system frequency, to eliminate the effect of electrostatic interference. The result is highly accurate and repeatable measurements. Even a small change in a measurement becomes a reliable diagnostic indicator.

If you are looking for new or well-maintained used Doble Engineering - M4000 Insulation Analyzer on rent or lease, contact us or request a quote today.

Read More
  • Configurations
  • Resources
--, 903-0031, M4300, MFL
See Configuration Details
  • M4300

    M4300 Field Transporter

  • MFL

    MFL Liquid Insulation Test Cell & Carrying Case

  • 903-0031

    Transportation Case, F2250 Or M4100

Standard Rental Accessories*
* Leased or Buy Used product accessories will be confirmed with quote.
  • Cable Ground M-Series 30 ft

    Qty: 1
  • Cord Power 14 awg x 3

    Qty: 1
  • Bag Large Accessory

    Qty: 2
  • Power Cord Keyed 3-Prong

    Qty: 1
  • AC Adapter for Toughbook

    Qty: 1
  • Battery Pack Lithium Ion

    Qty: 1
  • Test Lead Red

    Qty: 1
  • Test Lead Low Voltage Blue

    Qty: 1
  • Cable High Voltage

    Qty: 1
  • Conducting Collar Set

    Qty: 1
  • Strobe Light RWK

    Qty: 1
  • Power Cord Rackmount 6 ft

    Qty: 1
  • Cable W51 Field Adapter

    Qty: 1
  • Cable Instrument to PC M4100 10 ft

    Qty: 1
  • Cable Strobe Light

    Qty: 1
  • Sensor Temperature and Humidity for M4000

    Qty: 1
  • Cable Insulated Lead

    Qty: 2
  • Ground Lead with Clamps 3 ft

    Qty: 1
  • Ground Lead

    Qty: 5
  • Power Distribution Box

    Qty: 1
  • Sensor Temperature and Humidity 2 for M4100

    Qty: 1
  • Cable Adapter NEMA5 C320

    Qty: 1
  • Banana Plug, Quad Stack

    Qty: 1
  • Adapter P/ASY Bushing

    Qty: 1
  • Adapter P/A Bushing

    Qty: 1
  • Loopback Plug Connector

    Qty: 1
  • Loopback Receptacle Connector

    Qty: 1
  • Dolly Transport 2-Wheel

    Qty: 1
  • Case Transport

    Qty: 1
  • Test Cell MFL Liquid Insulation

    Qty: 1
  • Case

    Qty: 1
  • Laptop Panasonic Toughbook 19

    Qty: 1
  • Cover Front

    Qty: 1
  • Field Calibration Reference II Module

    Qty: 1
  • Hook High Voltage Cable

    Qty: 1
  • USB Drive with M4000 Software

    Qty: 1
  • Cable Safety Switch 8 ft

    Qty: 1
  • Cable Assembly Caton with Safety Switch

    Qty: 1
  • 8 ft Safety Switch Cable, M4000

    Qty: 1
  • Cable USB-A(m) - USB-B(m)

    Qty: 1
Rent or Lease

Check out first to get details on the cost.
